Electromagnetic brake for Bauer gear motor ESX010

Electromagnetic brake for Bauer gear motor ES010A9HA

Holding Brake ES/ZS:

Brake which do not perform frictional work in standard duty but are used principally for holding

a specifically reached position. In emergency situations a braking function may also be performed.

Typical usage: inverter controlled motors.

Working Brake ESX/ZSX:

brakes which perform frictional work in standard duty e.g. a braking function is performed.

The tolerance range up to -30% in new state has to be considered if the working brake is used as holding brake.

Commonly used models:ES010，ES027，ES040，ES070，ES125，ES200，ES250，ZS300，ZS500，ESX010，ESX027，ESX040，ESX070，ESX125，ESX200，ESX250，ZSX300，ZSX500......
